3D Printing Settings

On this page we have compiled our recommended 3D printing settings for AmeraLabs resins on the most popular 3D printers. Use these as a starting point and adjust based on the results you get. We recommend printing AmeraLabs town calibration part and following its guide to find perfect settings for your printer. If you find any discrepancies, or would like to share your settings, let us know by contacting our support: support@ameralabs.com

Choose your printer:

  • Anycubic Photon D2

    Anycubic Photon D2 DLP Printer 3D printing settings for AmeraLabs resins

    These are recommended 3D printing settings for Anycubic Photon D2 DLP. Use these as a starting point and adjust based on the results you get. We recommend printing AmeraLabs town calibration part and following its guide to find perfect settings for your printer.

    AMD-3 LED Black on Anycubic Photon D2 DLP

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 1.6 4 30 1 0 10 7 5 40 180
    0.050 1.2 4 20 1 0 10 7 5 40 180
    0.030 0.9 4 20 1 0 10 7 5 40 180

    AMD-3 LED Grey on Anycubic Photon D2 DLP

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 2.0 4 30 1 0 10 7 5 40 180
    0.050 1.5 4 20 1 0 10 7 5 40 180
    0.030 1.1 4 20 1 0 10 7 5 40 180

    TGM-7 LED Grey on Anycubic Photon D2 DLP

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 2.7 4 30 1 0 10 7 5 40 180
    0.050 2.0 4 30 1 0 10 7 5 40 180
    0.030 1.5 4 20 1 0 10 7 5 40 180

    TGM-7 LED White on Anycubic Photon D2 DLP

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 2.3 4 30 1 0 10 7 5 40 180
    0.050 1.8 4 20 1 0 10 7 5 40 180
    0.030 1.3 4 20 1 0 10 7 5 40 180

    DMD-21 LED Sand on Anycubic Photon D2 DLP

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 2.0 4 30 1 0 10 7 5 40 180
    0.050 1.5 4 20 1 0 10 7 5 40 180
    0.030 1.1 4 20 1 0 10 7 5 40 180

    DMD-31 DLP Beige and Grey on Anycubic Photon D2 DLP

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 3.4 4 40 1 0 10 7 5 40 180
    0.050 2.6 4 30 1 0 10 7 5 40 180
    0.030 1.9 4 30 1 0 10 7 5 40 180

  • Phrozen Sonic Mini 8K

    Phrozen Sonic Mini 8K Printer 3D printing settings for AmeraLabs resins

    These are recommended 3D printing settings for Phrozen Sonic Mini 8K 2019 3D printer. Use these as a starting point and adjust based on the results you get. We recommend printing AmeraLabs town calibration part and following its guide to find perfect settings for your printer.

    AMD-3 LED Black on Phrozen Sonic Mini 8K

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 1.7 4 20 11.5 0 10 7 5 40 180
    0.050 1.3 4 15 11.5 0 10 7 5 40 180
    0.030 1 4 15 11.5 0 10 7 5 40 180

    AMD-3 LED Grey on Phrozen Sonic Mini 8K

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 2.2 4 20 11.5 0 10 7 5 40 180
    0.050 1.6 4 15 11.5 0 10 7 5 40 180
    0.030 1.2 4 15 11.5 0 10 7 5 40 180

    TGM-7 LED Grey on Phrozen Sonic Mini 8K

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 1.9 4 20 11.5 0 10 7 5 40 180
    0.050 1.4 4 15 11.5 0 10 7 5 40 180
    0.030 1.1 4 15 11.5 0 10 7 5 40 180

    TGM-7 LED White on Phrozen Sonic Mini 8K

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 1.7 4 20 11.5 0 10 7 5 40 180
    0.050 1.3 4 15 11.5 0 10 7 5 40 180
    0.030 1.0 4 15 11.5 0 10 7 5 40 180

    DMD-21 LED Sand on Phrozen Sonic Mini 8K

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 2.2 4 20 11.5 0 10 7 5 40 180
    0.050 1.6 4 15 11.5 0 10 7 5 40 180
    0.030 1.2 4 15 11.5 0 10 7 5 40 180

    DMD-31 DLP Beige and Grey on Phrozen Sonic Mini 8K

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 2.9 4 30 11.5 0 10 7 5 40 180
    0.050 2.2 4 25 11.5 0 10 7 5 40 180
    0.030 1.7 4 20 11.5 0 10 7 5 40 180

  • Phrozen Sonic

    Phrozen Sonic Printer 3D printing settings for AmeraLabs resins

    These are recommended 3D printing settings for Phrozen Sonic 3D printer (monochrome LCD, ParaLED V3.0). Use these as a starting point and adjust based on the results you get. We recommend printing AmeraLabs town calibration part and following its guide to find perfect settings for your printer.

    AMD-3 LED Black on Phrozen Sonic

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 1 4 20 1 0 10 7 5 40 180
    0.050 0.7 4 20 1 0 10 7 5 40 180
    0.030 0.5 4 10 1 0 10 7 5 40 180

    AMD-3 LED Grey on Phrozen Sonic

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 1.2 4 20 1 0 10 7 5 40 180
    0.050 0.9 4 20 1 0 10 7 5 40 180
    0.030 0.7 4 20 1 0 10 7 5 40 180

    TGM-7 LED Grey on Phrozen Sonic

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 1.6 4 30 1 0 10 7 5 40 180
    0.050 1.2 4 20 1 0 10 7 5 40 180
    0.030 0.9 4 20 1 0 10 7 5 40 180

    TGM-7 LED White on Phrozen Sonic

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 1.4 4 30 1 0 10 7 5 40 180
    0.050 1.1 4 20 1 0 10 7 5 40 180
    0.030 0.8 4 20 1 0 10 7 5 40 180

    DMD-21 LED Sand on Phrozen Sonic

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 1.2 4 20 1 0 10 7 5 40 180
    0.050 0.9 4 20 1 0 10 7 5 40 180
    0.030 0.7 4 20 1 0 10 7 5 40 180

    DMD-31 DLP Beige and Grey on Phrozen Sonic

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 2 4 30 1 0 10 7 5 40 180
    0.050 1.5 4 20 1 0 10 7 5 40 180
    0.030 1.1 4 20 1 0 10 7 5 40 180

  • Phrozen Shuffle 2018

    Phrozen Shuffle 2018 Printer 3D printing settings for AmeraLabs resins

    These are recommended 3D printing settings for Phrozen Shuffle 2018 3D printer (2K, color LCD, ParaLED V1.0). Use these as a starting point and adjust based on the results you get. We recommend printing AmeraLabs town calibration part and following its guide to find perfect settings for your printer.

    AMD-3 LED Black on Phrozen Shuffle 2018

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 4.8 4 80 1 0 10 7 5 40 180
    0.050 3.6 4 60 1 0 10 7 5 40 180
    0.030 2.7 4 50 1 0 10 7 5 40 180

    AMD-3 LED Grey on Phrozen Shuffle 2018

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 6 4 90 1 0 10 7 5 40 180
    0.050 4.5 4 70 1 0 10 7 5 40 180
    0.030 3.4 4 60 1 0 10 7 5 40 180

    TGM-7 LED Grey on Phrozen Shuffle 2018

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 8 4 120 1 0 10 7 5 40 180
    0.050 6 4 90 1 0 10 7 5 40 180
    0.030 4.5 4 70 1 0 10 7 5 40 180

    TGM-7 LED White on Phrozen Shuffle 2018

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 7 4 120 1 0 10 7 5 40 180
    0.050 5.2 4 90 1 0 10 7 5 40 180
    0.030 4 4 70 1 0 10 7 5 40 180

    DMD-21 LED Sand on Phrozen Shuffle 2018

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 6 4 90 1 0 10 7 5 40 180
    0.050 4.5 4 70 1 0 10 7 5 40 180
    0.030 3.4 4 60 1 0 10 7 5 40 180

    DMD-31 DLP Beige and Grey on Phrozen Shuffle 2018

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 10.2 4 120 1 0 10 7 5 40 180
    0.050 7.7 4 90 1 0 10 7 5 40 180
    0.030 5.7 4 70 1 0 10 7 5 40 180

  • Phrozen Shuffle 2019

    Phrozen Shuffle 2019 Printer 3D printing settings for AmeraLabs resins

    These are recommended 3D printing settings for Phrozen Shuffle 2019 3D printer (2K, color LCD, ParaLED V2.0). Use these as a starting point and adjust based on the results you get. We recommend printing AmeraLabs town calibration part and following its guide to find perfect settings for your printer.

    AMD-3 LED Black on Phrozen Shuffle 2019

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 5.3 4 80 1 0 10 7 5 40 180
    0.050 4 4 60 1 0 10 7 5 40 180
    0.030 3 4 50 1 0 10 7 5 40 180

    AMD-3 LED Grey on Phrozen Shuffle 2019

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 6.7 4 100 1 0 10 7 5 40 180
    0.050 5.0 4 80 1 0 10 7 5 40 180
    0.030 3.8 4 60 1 0 10 7 5 40 180

    TGM-7 LED Grey on Phrozen Shuffle 2019

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 8.9 4 140 1 0 10 7 5 40 180
    0.050 6.7 4 100 1 0 10 7 5 40 180
    0.030 5.0 4 80 1 0 10 7 5 40 180

    TGM-7 LED White on Phrozen Shuffle 2019

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 7.8 4 140 1 0 10 7 5 40 180
    0.050 5.9 4 100 1 0 10 7 5 40 180
    0.030 4.4 4 80 1 0 10 7 5 40 180

    DMD-21 LED Sand on Phrozen Shuffle 2019

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 6.7 4 100 1 0 10 7 5 40 180
    0.050 5.0 4 80 1 0 10 7 5 40 180
    0.030 3.8 4 60 1 0 10 7 5 40 180

    DMD-31 DLP Beige and Grey on Phrozen Shuffle 2019

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 11.3 4 140 1 0 10 7 5 40 180
    0.050 8.5 4 100 1 0 10 7 5 40 180
    0.030 6.4 4 80 1 0 10 7 5 40 180

  • Phrozen Shuffle 4K 2019

    Phrozen Shuffle 4K 2019 Printer 3D printing settings for AmeraLabs resins

    These are recommended 3D printing settings for Phrozen Shuffle 4K 2019 3D printer (4K, color LCD, ParaLED V2.0). Use these as a starting point and adjust based on the results you get. We recommend printing AmeraLabs town calibration part and following its guide to find perfect settings for your printer.

    AMD-3 LED Black on Phrozen Shuffle 4K 2019

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 6.4 4 100 1 0 10 7 5 40 180
    0.050 4.8 4 80 1 0 10 7 5 40 180
    0.030 3.6 4 60 1 0 10 7 5 40 180

    AMD-3 LED Grey on Phrozen Shuffle 4K 2019

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 8.0 4 120 1 0 10 7 5 40 180
    0.050 6.0 4 90 1 0 10 7 5 40 180
    0.030 4.5 4 70 1 0 10 7 5 40 180

    TGM-7 LED Grey on Phrozen Shuffle 4K 2019

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 10.7 4 160 1 0 10 7 5 40 180
    0.050 8.0 4 120 1 0 10 7 5 40 180
    0.030 6.0 4 90 1 0 10 7 5 40 180

    TGM-7 LED White on Phrozen Shuffle 4K 2019

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 9.4 4 160 1 0 10 7 5 40 180
    0.050 7.0 4 120 1 0 10 7 5 40 180
    0.030 5.3 4 90 1 0 10 7 5 40 180

    DMD-21 LED Sand on Phrozen Shuffle 4K 2019

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 8.0 4 120 1 0 10 7 5 40 180
    0.050 6.0 4 90 1 0 10 7 5 40 180
    0.030 4.5 4 70 1 0 10 7 5 40 180

    DMD-31 DLP Beige and Grey on Phrozen Shuffle 4K 2019

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 13.6 4 160 1 0 10 7 5 40 180
    0.050 10.2 4 120 1 0 10 7 5 40 180
    0.030 7.7 4 90 1 0 10 7 5 40 180

  • Peopoly Phenom Noir

    We do not have recommended settings for Peopoly Phenom Noir 3D printer yet. Please contact us at support@ameralabs.com if you have found good settings for this printer.

  • Peopoly Phenom L

    We do not have recommended settings for Peopoly Phenom L 3D printer yet. Please contact us at support@ameralabs.com if you have found good settings for this printer.

  • Peopoly Phenom

    Peopoly Phenom Printer 3D printing settings for AmeraLabs resins

    These are recommended 3D printing settings for Peopoly Phenom 3D printer. Use these as a starting point and adjust based on the results you get. We recommend printing AmeraLabs town calibration part and following its guide to find perfect settings for your printer.

    AMD-3 LED Black on Peopoly Phenom

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 8.7 4 130 1 0 10 7 5 40 180
    0.050 6.5 4 100 1 0 10 7 5 40 180
    0.030 4.9 4 80 1 0 10 7 5 40 180

    AMD-3 LED Grey on Peopoly Phenom

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 10.8 4 170 1 0 10 7 5 40 180
    0.050 8.1 4 130 1 0 10 7 5 40 180
    0.030 6.1 4 100 1 0 10 7 5 40 180

    TGM-7 LED Grey on Peopoly Phenom

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 14.4 4 220 1 0 10 7 5 40 180
    0.050 10.8 4 170 1 0 10 7 5 40 180
    0.030 8.1 4 130 1 0 10 7 5 40 180

    TGM-7 LED White on Peopoly Phenom

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 12.6 4 220 1 0 10 7 5 40 180
    0.050 9.5 4 170 1 0 10 7 5 40 180
    0.030 7.1 4 130 1 0 10 7 5 40 180

    DMD-21 LED Sand on Peopoly Phenom

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 10.8 4 170 1 0 10 7 5 40 180
    0.050 8.1 4 130 1 0 10 7 5 40 180
    0.030 6.1 4 100 1 0 10 7 5 40 180

    DMD-31 DLP Beige and Grey on Peopoly Phenom

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 18.4 4 180 1 0 10 7 5 40 180
    0.050 13.8 4 160 1 0 10 7 5 40 180
    0.030 10.3 4 120 1 0 10 7 5 40 180

  • Nova3D Elfin

    We do not have recommended settings for Nova3D Elfin 3D printer yet. Please contact us at support@ameralabs.com if you have found good settings for this printer.

  • Nova3D Bene4 Mono

    We do not have recommended settings for Nova3D Bene4 mono 3D printer yet. Please contact us at support@ameralabs.com if you have found good settings for this printer.

  • Nova3D Bene4

    We do not have recommended settings for Nova3D Bene4 3D printer yet. Please contact us at support@ameralabs.com if you have found good settings for this printer.

  • Monoprice MP Mini

    We do not have recommended settings for Monoprice MP Mini 3D printer yet. Please contact us at support@ameralabs.com if you have found good settings for this printer.

  • Phrozen Sonic 4K

    Phrozen Sonic 4K Printer 3D printing settings for AmeraLabs resins

    These are recommended 3D printing settings for Phrozen Sonic 4K. Use these as a starting point and adjust based on the results you get. We recommend printing AmeraLabs town calibration part and following its guide to find perfect settings for your printer.

    AMD-3 LED Black on Phrozen Sonic 4K

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 1.9 4 30 11.5 0 10 7 5 40 180
    0.050 1.4 4 30 11.5 0 10 7 5 40 180
    0.030 1.1 4 20 11.5 0 10 7 5 40 180

    AMD-3 LED Grey on Phrozen Sonic 4K

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 2.4 4 40 11.5 0 10 7 5 40 180
    0.050 1.8 4 30 11.5 0 10 7 5 40 180
    0.030 1.4 4 30 11.5 0 10 7 5 40 180

    TGM-7 LED Grey on Phrozen Sonic 4K

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 3 4 50 11.5 0 10 7 5 40 180
    0.050 2.3 4 40 11.5 0 10 7 5 40 180
    0.030 1.7 4 30 11.5 0 10 7 5 40 180

    TGM-7 LED White on Phrozen Sonic 4K

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 2.7 4 50 11.5 0 10 7 5 40 180
    0.050 2.1 4 40 11.5 0 10 7 5 40 180
    0.030 1.6 4 30 11.5 0 10 7 5 40 180

    DMD-21 LED Sand on Phrozen Sonic 4K

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 2.4 4 40 11.5 0 10 7 5 40 180
    0.050 1.8 4 30 11.5 0 10 7 5 40 180
    0.030 1.4 4 30 11.5 0 10 7 5 40 180

    DMD-31 DLP Beige and Grey on Phrozen Sonic 4K

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 4.1 4 50 11.5 0 10 7 5 40 180
    0.050 3.1 4 40 11.5 0 10 7 5 40 180
    0.030 2.3 4 30 11.5 0 10 7 5 40 180

  • Phrozen Sonic Mini

    Phrozen Sonic Mini Printer 3D printing settings for AmeraLabs resins

    These are recommended 3D printing settings for Phrozen Sonic Mini 3D printer (monochrome LCD, ParaLED V2 Lite). Use these as a starting point and adjust based on the results you get. We recommend printing AmeraLabs town calibration part and following its guide to find perfect settings for your printer.

    AMD-3 LED Black on Phrozen Sonic Mini

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 2.6 4 40 11.5 0 10 7 5 40 180
    0.050 1.8 4 30 11.5 0 10 7 5 40 180
    0.030 1.5 4 30 11.5 0 10 7 5 40 180

    AMD-3 LED Grey on Phrozen Sonic Mini

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 3.3 4 50 11.5 0 10 7 5 40 180
    0.050 2.3 4 40 11.5 0 10 7 5 40 180
    0.030 1.8 4 30 11.5 0 10 7 5 40 180

    TGM-7 LED Grey on Phrozen Sonic Mini

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 3.9 4 60 11.5 0 10 7 5 40 180
    0.050 2.9 4 50 11.5 0 10 7 5 40 180
    0.030 2.3 4 40 11.5 0 10 7 5 40 180

    TGM-7 LED White on Phrozen Sonic Mini

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 3.6 4 60 11.5 0 10 7 5 40 180
    0.050 2.6 4 50 11.5 0 10 7 5 40 180
    0.030 2 4 40 11.5 0 10 7 5 40 180

    DMD-21 LED Sand on Phrozen Sonic Mini

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 3.3 4 50 11.5 0 10 7 5 40 180
    0.050 2.3 4 40 11.5 0 10 7 5 40 180
    0.030 1.8 4 30 11.5 0 10 7 5 40 180

    DMD-31 DLP Beige and Grey on Phrozen Sonic Mini

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 5.2 4 60 11.5 0 10 7 5 40 180
    0.050 3.9 4 40 11.5 0 10 7 5 40 180
    0.030 2.9 4 30 11.5 0 10 7 5 40 180

  • Phrozen Sonic Mini 4K

    Phrozen Sonic Mini 4K Printer 3D printing settings for AmeraLabs resins

    These are recommended 3D printing settings for Phrozen Sonic Mini 4K 2019 3D printer. Use these as a starting point and adjust based on the results you get. We recommend printing AmeraLabs town calibration part and following its guide to find perfect settings for your printer.

    AMD-3 LED Black on Phrozen Sonic Mini 4K

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 2.1 4 40 11.5 0 10 7 5 40 180
    0.050 1.6 4 30 11.5 0 10 7 5 40 180
    0.030 1.2 4 20 11.5 0 10 7 5 40 180

    AMD-3 LED Grey on Phrozen Sonic Mini 4K

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 2.7 4 40 11.5 0 10 7 5 40 180
    0.050 2.0 4 30 11.5 0 10 7 5 40 180
    0.030 1.5 4 30 11.5 0 10 7 5 40 180

    TGM-7 LED Grey on Phrozen Sonic Mini 4K

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 3.3 4 50 11.5 0 10 7 5 40 180
    0.050 2.5 4 40 11.5 0 10 7 5 40 180
    0.030 1.9 4 30 11.5 0 10 7 5 40 180

    TGM-7 LED White on Phrozen Sonic Mini 4K

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 3 4 50 11.5 0 10 7 5 40 180
    0.050 2.3 4 40 11.5 0 10 7 5 40 180
    0.030 1.7 4 30 11.5 0 10 7 5 40 180

    DMD-21 LED Sand on Phrozen Sonic Mini 4K

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 2.7 4 40 11.5 0 10 7 5 40 180
    0.050 2.0 4 30 11.5 0 10 7 5 40 180
    0.030 1.5 4 30 11.5 0 10 7 5 40 180

    DMD-31 DLP Beige and Grey on Phrozen Sonic Mini 4K

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 4.5 4 50 11.5 0 10 7 5 40 180
    0.050 3.4 4 40 11.5 0 10 7 5 40 180
    0.030 2.6 4 30 11.5 0 10 7 5 40 180

  • Zortrax Inkspire

    Zortrax Inkspire Printer 3D printing settings for AmeraLabs resins

    These are recommended 3D printing settings for Zortrax Inkspire 3D printer. Use these as a starting point and adjust based on the results you get. We recommend printing AmeraLabs town calibration part and following its guide to find perfect settings for your printer.

    AMD-3 LED Black on Zortrax Inkspire

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Exposure Off Time (s) Bottom Exposure Off Time (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 4 4 60 1 0 10 7 5 40 180
    0.050 3 4 50 1 0 10 7 5 40 180
    0.030 2.25 4 40 1 0 10 7 5 40 180

    AMD-3 LED Grey on Zortrax Inkspire

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Exposure Off Time (s) Bottom Exposure Off Time (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 4.75 4 70 1 0 10 7 5 40 180
    0.050 3.5 4 60 1 0 10 7 5 40 180
    0.030 2.75 4 40 1 0 10 7 5 40 180

    TGM-7 LED Grey on Zortrax Inkspire

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Exposure Off Time (s) Bottom Exposure Off Time (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 6.2 4 100 1 0 10 7 5 40 180
    0.050 4.7 4 70 1 0 10 7 5 40 180
    0.030 3.5 4 60 1 0 10 7 5 40 180

    TGM-7 LED Grey on Zortrax Inkspire

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Exposure Off Time (s) Bottom Exposure Off Time (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 5.5 4 100 1 0 10 7 5 40 180
    0.050 4.1 4 70 1 0 10 7 5 40 180
    0.030 3.1 4 60 1 0 10 7 5 40 180

    DMD-21 LED Sand on Zortrax Inkspire

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Exposure Off Time (s) Bottom Exposure Off Time (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 4.75 4 70 1 0 10 7 5 40 180
    0.050 3.5 4 60 1 0 10 7 5 40 180
    0.030 2.75 4 40 1 0 10 7 5 40 180

    DMD-31 DLP Beige and Grey on Zortrax Inkspire

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Exposure Off Time (s) Bottom Exposure Off Time (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 7.9 4 90 1 0 10 7 5 40 180
    0.050 6.0 4 70 1 0 10 7 5 40 180
    0.030 4.5 4 60 1 0 10 7 5 40 180

  • Wanhao D8

    Wanhao D8 Printer 3D printing settings for AmeraLabs resins

    These are recommended 3D printing settings for Wanhao D8 3D printer. Use these as a starting point and adjust based on the results you get. We recommend printing AmeraLabs town calibration part and following its guide to find perfect settings for your printer.

    AMD-3 LED Black on Wanhao D8

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 8 4 120 1 0 10 7 5 40 180
    0.050 6 4 90 1 0 10 7 5 40 180
    0.030 4.5 4 70 1 0 10 7 5 40 180

    AMD-3 LED Grey on Wanhao D8

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 10 4 150 1 0 10 7 5 40 180
    0.050 7.5 4 120 1 0 10 7 5 40 180
    0.030 5.6 4 90 1 0 10 7 5 40 180

    TGM-7 LED Grey on Wanhao D8

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 13.3 4 200 1 0 10 7 5 40 180
    0.050 10 4 150 1 0 10 7 5 40 180
    0.030 7.5 4 120 1 0 10 7 5 40 180

    TGM-7 LED White on Wanhao D8

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 11.7 4 200 1 0 10 7 5 40 180
    0.050 8.8 4 150 1 0 10 7 5 40 180
    0.030 6.5 4 120 1 0 10 7 5 40 180

    DMD-21 LED Sand on Wanhao D8

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 10 4 150 1 0 10 7 5 40 180
    0.050 7.5 4 120 1 0 10 7 5 40 180
    0.030 5.6 4 90 1 0 10 7 5 40 180

    DMD-31 DLP Beige and Grey on Wanhao D8

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 17 4 180 1 0 10 7 5 40 180
    0.050 12.8 4 160 1 0 10 7 5 40 180
    0.030 9.6 4 120 1 0 10 7 5 40 180

  • Wanhao D7 V1.5 Plus

    Wanhao D7 V1.5 Plus Printer 3D printing settings for AmeraLabs resins

    These are recommended 3D printing settings for Wanhao D7 V1.5 Plus 3D printer. Use these as a starting point and adjust based on the results you get. We recommend printing AmeraLabs town calibration part and following its guide to find perfect settings for your printer.

    AMD-3 LED Black on Wanhao D7 V1.5 Plus

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 8 4 120 1 0 10 7 5 40 180
    0.050 6 4 90 1 0 10 7 5 40 180
    0.030 4.5 4 70 1 0 10 7 5 40 180

    AMD-3 LED Grey on Wanhao D7 V1.5 Plus

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 10 4 150 1 0 10 7 5 40 180
    0.050 7.5 4 120 1 0 10 7 5 40 180
    0.030 5.6 4 90 1 0 10 7 5 40 180

    TGM-7 LED Grey on Wanhao D7 V1.5 Plus

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 13.3 4 200 1 0 10 7 5 40 180
    0.050 10.0 4 150 1 0 10 7 5 40 180
    0.030 7.5 4 120 1 0 10 7 5 40 180

    TGM-7 LED White on Wanhao D7 V1.5 Plus

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 11.7 4 200 1 0 10 7 5 40 180
    0.050 8.8 4 150 1 0 10 7 5 40 180
    0.030 6.5 4 120 1 0 10 7 5 40 180

    DMD-21 LED Sand on Wanhao D7 V1.5 Plus

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 10 4 150 1 0 10 7 5 40 180
    0.050 7.5 4 120 1 0 10 7 5 40 180
    0.030 5.6 4 90 1 0 10 7 5 40 180

    DMD-31 DLP Beige and Grey on Wanhao D7 V1.5 Plus

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 17 4 180 1 0 10 7 5 40 180
    0.050 12.8 4 150 1 0 10 7 5 40 180
    0.030 9.6 4 120 1 0 10 7 5 40 180

  • Uniz Slash Plus

    Uniz Slash Plus Printer 3D printing settings for AmeraLabs resins

    These are recommended 3D printing settings for Uniz Slash Plus 3D printer. Use these as a starting point and adjust based on the results you get. We recommend printing AmeraLabs town calibration part and following its guide to find perfect settings for your printer.

    AMD-3 LED Black on Uniz Slash Plus

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 4 4 24 1 0 10 7 5 40 180
    0.050 3 4 20 1 0 10 7 5 40 180
    0.030 2.3 4 16 1 0 10 7 5 40 180

    AMD-3 LED Grey on Uniz Slash Plus

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 5 4 32 1 0 10 7 5 40 180
    0.050 3.8 4 24 1 0 10 7 5 40 180
    0.030 2.8 4 20 1 0 10 7 5 40 180

    TGM-7 LED Grey on Uniz Slash Plus

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 6.7 4 40 1 0 10 7 5 40 180
    0.050 5 4 32 1 0 10 7 5 40 180
    0.030 3.8 4 24 1 0 10 7 5 40 180

    TGM-7 LED White on Uniz Slash Plus

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 5.9 4 40 1 0 10 7 5 40 180
    0.050 4.4 4 32 1 0 10 7 5 40 180
    0.030 3.3 4 24 1 0 10 7 5 40 180

    DMD-21 LED Sand on Uniz Slash Plus

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 5 4 32 1 0 10 7 5 40 180
    0.050 3.8 4 24 1 0 10 7 5 40 180
    0.030 2.8 4 20 1 0 10 7 5 40 180

    DMD-31 DLP Beige and Grey on Uniz Slash Plus

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 8.6 4 90 1 0 10 7 5 40 180
    0.050 6.5 4 70 1 0 10 7 5 40 180
    0.030 4.8 4 50 1 0 10 7 5 40 180

  • Uniz Slash 2

    Uniz Slash 2 Printer 3D printing settings for AmeraLabs resins

    These are recommended 3D printing settings for Uniz Slash 2 3D printer. Use these as a starting point and adjust based on the results you get. We recommend printing AmeraLabs town calibration part and following its guide to find perfect settings for your printer.

    AMD-3 LED Black on Uniz Slash 2

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 3.7 4 30 1 0 10 7 5 40 180
    0.050 2.8 4 25 1 0 10 7 5 40 180
    0.030 2.1 4 20 1 0 10 7 5 40 180

    AMD-3 LED Grey on Uniz Slash 2

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 4.7 4 35 1 0 10 7 5 40 180
    0.050 3.5 4 30 1 0 10 7 5 40 180
    0.030 2.6 4 20 1 0 10 7 5 40 180

    TGM-7 LED Grey on Uniz Slash 2

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 6.2 4 50 1 0 10 7 5 40 180
    0.050 4.7 4 35 1 0 10 7 5 40 180
    0.030 3.5 4 30 1 0 10 7 5 40 180

    TGM-7 LED White on Uniz Slash 2

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 5.5 4 50 1 0 10 7 5 40 180
    0.050 4.1 4 35 1 0 10 7 5 40 180
    0.030 3.1 4 30 1 0 10 7 5 40 180

    DMD-21 LED Sand on Uniz Slash 2

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 4.7 4 35 1 0 10 7 5 40 180
    0.050 3.5 4 30 1 0 10 7 5 40 180
    0.030 2.6 4 20 1 0 10 7 5 40 180

    DMD-31 DLP Beige and Grey on Uniz Slash 2

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 7.9 4 90 1 0 10 7 5 40 180
    0.050 6 4 70 1 0 10 7 5 40 180
    0.030 4.5 4 50 1 0 10 7 5 40 180

  • Qidi Shadow 5.5S

    Qidi Shadow 5.5S Printer 3D printing settings for AmeraLabs resins

    These are recommended 3D printing settings for Qidi Shadow 5.5S 3D printer. Use these as a starting point and adjust based on the results you get. We recommend printing AmeraLabs town calibration part and following its guide to find perfect settings for your printer.

    AMD-3 LED Black on Qidi Shadow 5.5S

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 9.1 4 140 1 0 10 7 5 40 180
    0.050 6.8 4 110 1 0 10 7 5 40 180
    0.030 5.1 4 80 1 0 10 7 5 40 180

    AMD-3 LED Grey on Qidi Shadow 5.5S

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 11.3 4 170 1 0 10 7 5 40 180
    0.050 8.5 4 130 1 0 10 7 5 40 180
    0.030 6.4 4 100 1 0 10 7 5 40 180

    TGM-7 LED Grey on Qidi Shadow 5.5S

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 15.1 4 230 1 0 10 7 5 40 180
    0.050 11.3 4 170 1 0 10 7 5 40 180
    0.030 8.5 4 130 1 0 10 7 5 40 180

    TGM-7 LED White on Qidi Shadow 5.5S

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 13.2 4 230 1 0 10 7 5 40 180
    0.050 9.9 4 170 1 0 10 7 5 40 180
    0.030 7.5 4 130 1 0 10 7 5 40 180

    DMD-21 LED Sand on Qidi Shadow 5.5S

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 11.3 4 170 1 0 10 7 5 40 180
    0.050 8.5 4 130 1 0 10 7 5 40 180
    0.030 6.4 4 100 1 0 10 7 5 40 180

    DMD-31 DLP Beige and Grey on Qidi Shadow 5.5S

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 19.3 4 180 1 0 10 7 5 40 180
    0.050 14.5 4 150 1 0 10 7 5 40 180
    0.030 10.8 4 120 1 0 10 7 5 40 180

  • Prusa SL1S

    Prusa SL1S Printer 3D printing settings for AmeraLabs resins

    These are recommended 3D printing settings for Prusa SL1S 3D printer. Use these as a starting point and adjust based on the results you get. We recommend printing AmeraLabs town calibration part and following its guide to find perfect settings for your printer. You can also find the latest profiles in PrusaSlicer.

    AMD-3 LED Black on Prusa SL1S

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 1.6 4 30 1 0 10 7 5 40 180
    0.050 1.2 4 20 1 0 10 7 5 40 180
    0.030 0.9 4 20 1 0 10 7 5 40 180

    AMD-3 LED Grey on Prusa SL1S

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 2.0 4 30 1 0 10 7 5 40 180
    0.050 1.5 4 30 1 0 10 7 5 40 180
    0.030 1.1 4 20 1 0 10 7 5 40 180

    TGM-7 LED Grey on Prusa SL1S

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 2.7 4 40 1 0 10 7 5 40 180
    0.050 2 4 30 1 0 10 7 5 40 180
    0.030 1.5 4 30 1 0 10 7 5 40 180

    TGM-7 LED White on Prusa SL1S

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 2.4 4 40 1 0 10 7 5 40 180
    0.050 1.7 4 30 1 0 10 7 5 40 180
    0.030 1.2 4 30 1 0 10 7 5 40 180

    DMD-21 LED Sand on Prusa SL1S

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 2 4 30 1 0 10 7 5 40 180
    0.050 1.5 4 30 1 0 10 7 5 40 180
    0.030 1.1 4 20 1 0 10 7 5 40 180

    DMD-31 DLP Beige and Grey on Prusa SL1S

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 3.4 4 40 1 0 10 7 5 40 180
    0.050 2.6 4 30 1 0 10 7 5 40 180
    0.030 1.9 4 20 1 0 10 7 5 40 180

  • Prusa SL1 Printer

    Prusa SL1 Printer 3D printing settings for AmeraLabs resins

    These are recommended 3D printing settings for Prusa SL1 3D printer. Use these as a starting point and adjust based on the results you get. We recommend printing AmeraLabs town calibration part and following its guide to find perfect settings for your printer. You can also find the latest profiles in PrusaSlicer.

    AMD-3 LED Black on Prusa SL1

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 5.6 4 50 1 0 10 7 5 40 180
    0.050 4.2 4 35 1 0 10 7 5 40 180
    0.030 3.2 4 30 1 0 10 7 5 40 180

    AMD-3 LED Grey on Prusa SL1

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 7 4 50 1 0 10 7 5 40 180
    0.050 5 4 35 1 0 10 7 5 40 180
    0.030 3.9 4 30 1 0 10 7 5 40 180

    TGM-7 LED Grey on Prusa SL1

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 10 4 50 1 0 10 7 5 40 180
    0.050 7 4 35 1 0 10 7 5 40 180
    0.030 5 4 30 1 0 10 7 5 40 180

    TGM-7 LED White on Prusa SL1

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 8.5 4 50 1 0 10 7 5 40 180
    0.050 6.1 4 35 1 0 10 7 5 40 180
    0.030 4.5 4 30 1 0 10 7 5 40 180

    DMD-21 LED Sand on Prusa SL1

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 7 4 50 1 0 10 7 5 40 180
    0.050 5.3 4 35 1 0 10 7 5 40 180
    0.030 3.9 4 30 1 0 10 7 5 40 180

    DMD-31 DLP Beige and Grey on Prusa SL1

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 12 4 120 1 0 10 7 5 40 180
    0.050 9 4 90 1 0 10 7 5 40 180
    0.030 6.8 4 70 1 0 10 7 5 40 180

  • Phrozen Transform 4K Fast

    Phrozen Transform 4K Fast Printer 3D printing settings for AmeraLabs resins

    These are recommended 3D printing settings for Phrozen Transform 4K Fast 3D printer (4K, color LCD, ParaLED V2.0). Use these as a starting point and adjust based on the results you get. We recommend printing AmeraLabs town calibration part and following its guide to find perfect settings for your printer.

    AMD-3 LED Black on Phrozen Transform 4K Fast

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 3 4 50 11.5 0 10 7 5 40 180
    0.050 2.2 4 40 11.5 0 10 7 5 40 180
    0.030 1.7 4 30 11.5 0 10 7 5 40 180

    AMD-3 LED Grey on Phrozen Transform 4K Fast

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 3.7 4 60 11.5 0 10 7 5 40 180
    0.050 2.8 4 50 11.5 0 10 7 5 40 180
    0.030 2.1 4 40 11.5 0 10 7 5 40 180

    TGM-7 LED Grey on Phrozen Transform 4K Fast

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 5 4 80 11.5 0 10 7 5 40 180
    0.050 3.7 4 60 11.5 0 10 7 5 40 180
    0.030 2.8 4 50 11.5 0 10 7 5 40 180

    TGM-7 LED White on Phrozen Transform 4K Fast

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 4.4 4 80 11.5 0 10 7 5 40 180
    0.050 3.3 4 60 11.5 0 10 7 5 40 180
    0.030 2.5 4 50 11.5 0 10 7 5 40 180

    DMD-21 LED Sand on Phrozen Transform 4K Fast

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 3.7 4 60 11.5 0 10 7 5 40 180
    0.050 2.8 4 50 11.5 0 10 7 5 40 180
    0.030 2.1 4 40 11.5 0 10 7 5 40 180

    DMD-31 DLP Beige and Grey on Phrozen Transform 4K Fast

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 6.3 4 70 11.5 0 10 7 5 40 180
    0.050 4.8 4 50 11.5 0 10 7 5 40 180
    0.030 3.6 4 40 11.5 0 10 7 5 40 180

  • Phrozen Transform 4K

    Phrozen Transform 4K Printer 3D printing settings for AmeraLabs resins

    These are recommended 3D printing settings for Phrozen Transform 4K 3D printer (4K, color LCD, ParaLED V2.0). Use these as a starting point and adjust based on the results you get. We recommend printing AmeraLabs town calibration part and following its guide to find perfect settings for your printer.

    AMD-3 LED Black on Phrozen Transform 4K

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 6 4 90 11.5 0 10 7 5 40 180
    0.050 4.5 4 70 11.5 0 10 7 5 40 180
    0.030 3.4 4 60 11.5 0 10 7 5 40 180

    AMD-3 LED Grey on Phrozen Transform 4K

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 7.5 4 120 11.5 0 10 7 5 40 180
    0.050 5.6 4 90 11.5 0 10 7 5 40 180
    0.030 4.2 4 70 11.5 0 10 7 5 40 180

    TGM-7 LED Grey on Phrozen Transform 4K

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 10 4 150 11.5 0 10 7 5 40 180
    0.050 7.5 4 120 11.5 0 10 7 5 40 180
    0.030 5.6 4 90 11.5 0 10 7 5 40 180

    TGM-7 LED White on Phrozen Transform 4K

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 8.8 4 150 11.5 0 10 7 5 40 180
    0.050 6.5 4 120 11.5 0 10 7 5 40 180
    0.030 4.9 4 90 11.5 0 10 7 5 40 180

    DMD-21 LED Sand on Phrozen Transform 4K

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 7.5 4 120 11.5 0 10 7 5 40 180
    0.050 5.6 4 90 11.5 0 10 7 5 40 180
    0.030 4.2 4 70 11.5 0 10 7 5 40 180

    DMD-31 DLP Beige and Grey on Phrozen Transform 4K

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 12.7 4 140 11.5 0 10 7 5 40 180
    0.050 9.5 4 100 11.5 0 10 7 5 40 180
    0.030 7.1 4 80 11.5 0 10 7 5 40 180

  • Phrozen Sonic Mighty 4K

    Phrozen Sonic Mighty 4K Printer 3D printing settings for AmeraLabs resins

    These are recommended 3D printing settings for Phrozen Sonic Mighty 4K 3D printer. Use these as a starting point and adjust based on the results you get. We recommend printing AmeraLabs town calibration part and following its guide to find perfect settings for your printer.

    AMD-3 LED Black on Phrozen Sonic Mighty 4K

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 2.1 4 40 11.5 0 10 7 5 40 180
    0.050 1.6 4 30 11.5 0 10 7 5 40 180
    0.030 1.2 4 20 11.5 0 10 7 5 40 180

    AMD-3 LED Grey on Phrozen Sonic Mighty 4K

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 2.7 4 40 11.5 0 10 7 5 40 180
    0.050 2.0 4 30 11.5 0 10 7 5 40 180
    0.030 1.5 4 30 11.5 0 10 7 5 40 180

    TGM-7 LED Grey on Phrozen Sonic Mighty 4K

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 3.3 4 50 11.5 0 10 7 5 40 180
    0.050 2.5 4 40 11.5 0 10 7 5 40 180
    0.030 1.9 4 30 11.5 0 10 7 5 40 180

    TGM-7 LED White on Phrozen Sonic Mighty 4K

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 3 4 50 11.5 0 10 7 5 40 180
    0.050 2.3 4 40 11.5 0 10 7 5 40 180
    0.030 1.7 4 30 11.5 0 10 7 5 40 180

    DMD-21 LED Sand on Phrozen Sonic Mighty 4K

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 2.7 4 40 11.5 0 10 7 5 40 180
    0.050 2.0 4 30 11.5 0 10 7 5 40 180
    0.030 1.5 4 30 11.5 0 10 7 5 40 180

    DMD-31 DLP Beige and Grey on Phrozen Sonic Mighty 4K

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 4.5 4 50 11.5 0 10 7 5 40 180
    0.050 3.4 4 40 11.5 0 10 7 5 40 180
    0.030 2.6 4 30 11.5 0 10 7 5 40 180

  • Longer Orange 3D

    We do not have recommended settings for Longer Orange 3D printer yet. Please contact us at support@ameralabs.com if you have found good settings for this printer.

  • Kudo3D Bean

    Kudo3D Bean Printer 3D printing settings for AmeraLabs resins

    These are recommended 3D printing settings for Kudo3D Bean 3D printer. Use these as a starting point and adjust based on the results you get. We recommend printing AmeraLabs town calibration part and following its guide to find perfect settings for your printer.

    AMD-3 LED Black on Kudo3D Bean

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 2.9 4 50 1 0 10 7 5 40 180
    0.050 2.2 4 40 1 0 10 7 5 40 180
    0.030 1.7 4 30 1 0 10 7 5 40 180

    AMD-3 LED Grey on Kudo3D Bean

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 3.7 4 60 1 0 10 7 5 40 180
    0.050 2.8 4 50 1 0 10 7 5 40 180
    0.030 2.1 4 40 1 0 10 7 5 40 180

    TGM-7 LED Grey on Kudo3D Bean

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 4.9 4 80 1 0 10 7 5 40 180
    0.050 3.7 4 60 1 0 10 7 5 40 180
    0.030 2.8 4 50 1 0 10 7 5 40 180

    TGM-7 LED White on Kudo3D Bean

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 4.3 4 80 1 0 10 7 5 40 180
    0.050 3.2 4 60 1 0 10 7 5 40 180
    0.030 2.5 4 50 1 0 10 7 5 40 180

    DMD-21 LED Sand on Kudo3D Bean

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 3.7 4 60 1 0 10 7 5 40 180
    0.050 2.8 4 50 1 0 10 7 5 40 180
    0.030 2.1 4 40 1 0 10 7 5 40 180

    DMD-31 DLP Beige and Grey on Kudo3D Bean

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 6.3 4 70 1 0 10 7 5 40 180
    0.050 4.8 4 50 1 0 10 7 5 40 180
    0.030 3.6 4 40 1 0 10 7 5 40 180

  • Elegoo Mars Printer

    Elegoo Mars Printer 3D printing settings for AmeraLabs resins

    These are recommended 3D printing settings for Elegoo Mars 3D printer. Use these as a starting point and adjust based on the results you get. We recommend printing AmeraLabs town calibration part and following its guide to find perfect settings for your printer.

    AMD-3 LED Black on Elegoo Mars

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 4.8 4 80 11.5 0 10 7 5 40 180
    0.050 3.6 4 60 11.5 0 10 7 5 40 180
    0.030 2.7 4 50 11.5 0 10 7 5 40 180

    AMD-3 LED Grey on Elegoo Mars

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 6 4 90 11.5 0 10 7 5 40 180
    0.050 4.5 4 70 11.5 0 10 7 5 40 180
    0.030 3.4 4 60 11.5 0 10 7 5 40 180

    TGM-7 LED Grey on Elegoo Mars

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 7.5 4 120 11.5 0 10 7 5 40 180
    0.050 5.6 4 90 11.5 0 10 7 5 40 180
    0.030 4.2 4 70 11.5 0 10 7 5 40 180

    TGM-7 LED White on Elegoo Mars

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 6.7 4 120 11.5 0 10 7 5 40 180
    0.050 5 4 90 11.5 0 10 7 5 40 180
    0.030 3.8 4 70 11.5 0 10 7 5 40 180

    DMD-21 LED Sand on Elegoo Mars

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 6 4 90 11.5 0 10 7 5 40 180
    0.050 4.5 4 70 11.5 0 10 7 5 40 180
    0.030 3.4 4 60 11.5 0 10 7 5 40 180

    DMD-31 DLP Beige and Grey on Elegoo Mars

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 10.2 4 120 11.5 0 10 7 5 40 180
    0.050 7.7 4 90 11.5 0 10 7 5 40 180
    0.030 5.7 4 80 11.5 0 10 7 5 40 180

  • Creality LD-002R

    Creality LD-002R Printer 3D printing settings for AmeraLabs resins

    These are recommended 3D printing settings for Creality LD-002R 3D printer. Use these as a starting point and adjust based on the results you get. We recommend printing AmeraLabs town calibration part and following its guide to find perfect settings for your printer.

    AMD-3 LED Black on Creality LD-002R

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 4.3 4 70 1 0 10 7 5 40 180
    0.050 3.2 4 50 1 0 10 7 5 40 180
    0.030 2.4 4 40 1 0 10 7 5 40 180

    AMD-3 LED Grey on Creality LD-002R

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 5.3 4 80 1 0 10 7 5 40 180
    0.050 4.0 4 60 1 0 10 7 5 40 180
    0.030 3.0 4 50 1 0 10 7 5 40 180

    TGM-7 LED Grey on Creality LD-002R

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 7.1 4 110 1 0 10 7 5 40 180
    0.050 5.3 4 80 1 0 10 7 5 40 180
    0.030 4.0 4 60 1 0 10 7 5 40 180

    TGM-7 LED White on Creality LD-002R

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 6.2 4 110 1 0 10 7 5 40 180
    0.050 4.7 4 80 1 0 10 7 5 40 180
    0.030 3.5 4 60 1 0 10 7 5 40 180

    DMD-21 LED Sand on Creality LD-002R

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 5.3 4 80 1 0 10 7 5 40 180
    0.050 4.0 4 60 1 0 10 7 5 40 180
    0.030 3.0 4 50 1 0 10 7 5 40 180

    DMD-31 DLP Beige and Grey on Creality LD-002R

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 9.1 4 120 1 0 10 7 5 40 180
    0.050 6.8 4 100 1 0 10 7 5 40 180
    0.030 5.1 4 80 1 0 10 7 5 40 180

  • Creality LD-001

    We do not have recommended settings for Creality LD-001 3D printer yet. Please contact us at support@ameralabs.com if you have found good settings for this printer.

  • Asiga

    Download settings for Asiga 3D printers here: Ameralabs-Asiga-settings.7z

  • Anycubic Photon Zero

    We do not have recommended settings for Anycubic Photon Zero 3D printer yet. Please contact us at support@ameralabs.com if you have found good settings for this printer.

  • Anycubic Photon Mono X 6K

    Anycubic Photon Mono X 6K Printer 3D printing settings for AmeraLabs resins

    These are recommended 3D printing settings for Anycubic Photon Mono X 6K. Use these as a starting point and adjust based on the results you get. We recommend printing AmeraLabs town calibration part and following its guide to find perfect settings for your printer.

    AMD-3 LED Black on Anycubic Photon Mono X 6K

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min) LED POWER
    0.100 1.2 4 30 1 0 10 7 5 40 180 100%
    0.050 0.9 4 30 1 0 10 7 5 40 180 100%
    0.030 0.7 4 20 1 0 10 7 5 40 180 100%

    AMD-3 LED Grey on Anycubic Photon Mono X 6K

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min) LED POWER
    0.100 1.5 4 40 1 0 10 7 5 40 180 100%
    0.050 1.1 4 30 1 0 10 7 5 40 180 100%
    0.030 0.8 4 30 1 0 10 7 5 40 180 100%

    TGM-7 LED Grey on Anycubic Photon Mono X 6K

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min) LED POWER
    0.100 2 4 50 1 0 10 7 5 40 180 100%
    0.050 1.5 4 40 1 0 10 7 5 40 180 100%
    0.030 1.1 4 30 1 0 10 7 5 40 180 100%

    TGM-7 LED White on Anycubic Photon Mono X 6K

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min) LED POWER
    0.100 1.75 4 50 1 0 10 7 5 40 180 100%
    0.050 1.3 4 40 1 0 10 7 5 40 180 100%
    0.030 1.0 4 30 1 0 10 7 5 40 180 100%

    DMD-21 LED Sand on Anycubic Photon Mono X 6K

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min) LED POWER
    0.100 1.5 4 40 1 0 10 7 5 40 180 100%
    0.050 1.1 4 30 1 0 10 7 5 40 180 100%
    0.030 0.8 4 30 1 0 10 7 5 40 180 100%

    DMD-31 DLP Beige and Grey on Anycubic Photon Mono X 6K

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min) LED POWER
    0.100 2.5 4 50 1 0 10 7 5 40 180 100%
    0.050 1.9 4 40 1 0 10 7 5 40 180 100%
    0.030 1.4 4 30 1 0 10 7 5 40 180 100%

  • Anycubic Photon Mono X

    Anycubic Photon Mono X Printer 3D printing settings for AmeraLabs resins

    These are recommended 3D printing settings for Anycubic Photon Mono X 3D printer. Use these as a starting point and adjust based on the results you get. We recommend printing AmeraLabs town calibration part and following its guide to find perfect settings for your printer.

    AMD-3 LED Black on Anycubic Photon Mono X

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min) LED POWER
    0.100 1.4 4 30 1 0 10 7 5 40 180 75%
    0.050 1 4 30 1 0 10 7 5 40 180 75%
    0.030 0.8 4 20 1 0 10 7 5 40 180 75%

    AMD-3 LED Grey on Anycubic Photon Mono X

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min) LED POWER
    0.100 1.6 4 40 1 0 10 7 5 40 180 75%
    0.050 1.2 4 30 1 0 10 7 5 40 180 75%
    0.030 0.9 4 20 1 0 10 7 5 40 180 75%

    TGM-7 LED Grey on Anycubic Photon Mono X

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min) LED POWER
    0.100 1.5 4 30 1 0 10 7 5 40 180 75%
    0.050 1.1 4 20 1 0 10 7 5 40 180 75%
    0.030 0.9 4 15 1 0 10 7 5 40 180 75%

    TGM-7 LED White on Anycubic Photon Mono X

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min) LED POWER
    0.100 1.2 4 50 1 0 10 7 5 40 180 75%
    0.050 0.9 4 40 1 0 10 7 5 40 180 75%
    0.030 0.7 4 30 1 0 10 7 5 40 180 75%

    DMD-21 LED Sand on Anycubic Photon Mono X

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min) LED POWER
    0.100 1.6 4 40 1 0 10 7 5 40 180 75%
    0.050 1.2 4 30 1 0 10 7 5 40 180 75%
    0.030 0.9 4 20 1 0 10 7 5 40 180 75%

    DMD-31 DLP Beige and Grey on Anycubic Photon Mono X

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min) LED POWER
    0.100 2.0 4 60 1 0 10 7 5 40 180 75%
    0.050 1.5 4 40 1 0 10 7 5 40 180 75%
    0.030 1.2 4 30 1 0 10 7 5 40 180 75%

  • Anycubic Photon Mono SE

    Anycubic Photon Mono SE Printer 3D printing settings for AmeraLabs resins

    These are recommended 3D printing settings for Anycubic Photon Mono SE. Use these as a starting point and adjust based on the results you get. We recommend printing AmeraLabs town calibration part and following its guide to find perfect settings for your printer.

    AMD-3 LED Black on Anycubic Photon Mono SE

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min) LED POWER
    0.100 1.9 4 30 1 0 10 7 5 40 180 80%
    0.050 1.4 4 30 1 0 10 7 5 40 180 80%
    0.030 1.1 4 20 1 0 10 7 5 40 180 80%

    AMD-3 LED Grey on Anycubic Photon Mono SE

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min) LED POWER
    0.100 2.4 4 40 1 0 10 7 5 40 180 80%
    0.050 1.8 4 30 1 0 10 7 5 40 180 80%
    0.030 1.4 4 30 1 0 10 7 5 40 180 80%

    TGM-7 LED Grey on Anycubic Photon Mono SE

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min) LED POWER
    0.100 3 4 50 1 0 10 7 5 40 180 80%
    0.050 2.3 4 40 1 0 10 7 5 40 180 80%
    0.030 1.7 4 30 1 0 10 7 5 40 180 80%

    TGM-7 LED White on Anycubic Photon Mono SE

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min) LED POWER
    0.100 2.7 4 50 1 0 10 7 5 40 180 80%
    0.050 2 4 40 1 0 10 7 5 40 180 80%
    0.030 1.5 4 30 1 0 10 7 5 40 180 80%

    DMD-21 LED Sand on Anycubic Photon Mono SE

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min) LED POWER
    0.100 2.4 4 40 1 0 10 7 5 40 180 80%
    0.050 1.8 4 30 1 0 10 7 5 40 180 80%
    0.030 1.4 4 30 1 0 10 7 5 40 180 80%

    DMD-31 DLP Beige and Grey on Anycubic Photon Mono SE

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min) LED POWER
    0.100 4.1 4 80 1 0 10 7 5 40 180 80%
    0.050 3.1 4 60 1 0 10 7 5 40 180 80%
    0.030 2.3 4 50 1 0 10 7 5 40 180 80%

  • Anycubic Photon Mono 4K

    Anycubic Photon Mono 4K Printer 3D printing settings for AmeraLabs resins

    These are recommended 3D printing settings for Anycubic Photon Mono 4K. Use these as a starting point and adjust based on the results you get. We recommend printing AmeraLabs town calibration part and following its guide to find perfect settings for your printer.

    AMD-3 LED Black on Anycubic Photon Mono 4K

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min) LED POWER
    0.100 1.2 4 30 1 0 10 7 5 40 180 100%
    0.050 0.9 4 30 1 0 10 7 5 40 180 100%
    0.030 0.7 4 20 1 0 10 7 5 40 180 100%

    AMD-3 LED Grey on Anycubic Photon Mono 4K

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min) LED POWER
    0.100 1.5 4 40 1 0 10 7 5 40 180 100%
    0.050 1.1 4 30 1 0 10 7 5 40 180 100%
    0.030 0.8 4 30 1 0 10 7 5 40 180 100%

    TGM-7 LED Grey on Anycubic Photon Mono 4K

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min) LED POWER
    0.100 2 4 50 1 0 10 7 5 40 180 100%
    0.050 1.5 4 40 1 0 10 7 5 40 180 100%
    0.030 1.1 4 30 1 0 10 7 5 40 180 100%

    TGM-7 LED White on Anycubic Photon Mono 4K

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min) LED POWER
    0.100 1.75 4 50 1 0 10 7 5 40 180 100%
    0.050 1.2 4 40 1 0 10 7 5 40 180 100%
    0.030 1.0 4 30 1 0 10 7 5 40 180 100

    DMD-21 LED Sand on Anycubic Photon Mono 4K

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min) LED POWER
    0.100 1.5 4 40 1 0 10 7 5 40 180 100%
    0.050 1.1 4 30 1 0 10 7 5 40 180 100%
    0.030 0.8 4 30 1 0 10 7 5 40 180 100%

    DMD-31 DLP Beige and Grey on Anycubic Photon Mono 4K

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min) LED POWER
    0.100 2.5 4 50 1 0 10 7 5 40 180 100%
    0.050 1.9 4 40 1 0 10 7 5 40 180 100%
    0.030 1.4 4 30 1 0 10 7 5 40 180 100%

  • Anycubic Photon Mono

    We do not have recommended settings for Anycubic Photon Mono 3D printer yet. Please contact us at support@ameralabs.com if you have found good settings for this printer.

  • Anycubic Photon S

    Anycubic Photon S Printer 3D printing settings for AmeraLabs resins

    These are recommended 3D printing settings for Anycubic Photon S 3D printer (with 35W LED light source and color LCD). Use these as a starting point and adjust based on the results you get. We recommend printing AmeraLabs town calibration part and following its guide to find perfect settings for your printer.

    AMD-3 LED Black on Anycubic Photon S

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 6.4 4 100 1 0 10 7 5 40 180
    0.050 4.8 4 80 1 0 10 7 5 40 180
    0.030 3.6 4 60 1 0 10 7 5 40 180

    AMD-3 LED Grey on Anycubic Photon S

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 8 4 120 1 0 10 7 5 40 180
    0.050 6 4 90 1 0 10 7 5 40 180
    0.030 4.5 4 70 1 0 10 7 5 40 180

    TGM-7 LED Grey on Anycubic Photon S

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 10.7 4 160 1 0 10 7 5 40 180
    0.050 8.0 4 120 1 0 10 7 5 40 180
    0.030 6.0 4 90 1 0 10 7 5 40 180

    TGM-7 LED White on Anycubic Photon S

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 9.4 4 160 1 0 10 7 5 40 180
    0.050 7 4 120 1 0 10 7 5 40 180
    0.030 5.3 4 90 1 0 10 7 5 40 180

    DMD-21 LED Sand on Anycubic Photon S

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 8 4 120 1 0 10 7 5 40 180
    0.050 6 4 90 1 0 10 7 5 40 180
    0.030 4.5 4 70 1 0 10 7 5 40 180

    DMD-31 DLP Beige and Grey on Anycubic Photon S

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 13.6 4 160 1 0 10 7 5 40 180
    0.050 10.2 4 120 1 0 10 7 5 40 180
    0.030 7.7 4 90 1 0 10 7 5 40 180

  • Anycubic Photon

    Anycubic Photon Printer 3D printing settings for AmeraLabs resins

    These are recommended 3D printing settings for Anycubic Photon 3D printer (original version with 25W LED light source and color LCD). Use these as a starting point and adjust based on the results you get. We recommend printing AmeraLabs town calibration part and following its guide to find perfect settings for your printer.

    AMD-3 LED Black on Anycubic Photon

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 8.0 4 120 1 0 10 7 5 40 180
    0.050 6.5 4 90 1 0 10 7 5 40 180
    0.030 4.5 4 70 1 0 10 7 5 40 180

    AMD-3 LED Grey on Anycubic Photon

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 10 4 150 1 0 10 7 5 40 180
    0.050 7.5 4 120 1 0 10 7 5 40 180
    0.030 5.6 4 90 1 0 10 7 5 40 180

    TGM-7 LED Grey on Anycubic Photon

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 12.5 4 190 1 0 10 7 5 40 180
    0.050 9.4 4 150 1 0 10 7 5 40 180
    0.030 7.0 4 110 1 0 10 7 5 40 180

    TGM-7 LED White on Anycubic Photon

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 11.5 4 190 1 0 10 7 5 40 180
    0.050 8.5 4 150 1 0 10 7 5 40 180
    0.030 6.3 4 110 1 0 10 7 5 40 180

    DMD-21 LED Sand on Anycubic Photon

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 10 4 150 1 0 10 7 5 40 180
    0.050 7.5 4 120 1 0 10 7 5 40 180
    0.030 5.6 4 90 1 0 10 7 5 40 180

    DMD-31 DLP Beige and Grey on Anycubic Photon

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Rest Time After Retract (s) Bottom Rest Time After Retract (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 17 4 180 1 0 10 7 5 40 180
    0.050 12.8 4 150 1 0 10 7 5 40 180
    0.030 9.6 4 120 1 0 10 7 5 40 180

  • Elegoo Mars Pro

    Elegoo Mars Pro Printer 3D printing settings for AmeraLabs resins

    These are recommended 3D printing settings for Elegoo Mars Pro 3D printer. Use these as a starting point and adjust based on the results you get. We recommend printing AmeraLabs town calibration part and following its guide to find perfect settings for your printer.

    AMD-3 LED Black on Elegoo Mars Pro

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 4.3 4 70 11.5 0 10 7 5 40 180
    0.050 3.2 4 50 11.5 0 10 7 5 40 180
    0.030 2.4 4 40 11.5 0 10 7 5 40 180

    AMD-3 LED Grey on Elegoo Mars Pro

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 5.3 4 80 11.5 0 10 7 5 40 180
    0.050 4.0 4 60 11.5 0 10 7 5 40 180
    0.030 3.0 4 50 11.5 0 10 7 5 40 180

    TGM-7 LED Grey on Elegoo Mars Pro

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 6.7 4 100 11.5 0 10 7 5 40 180
    0.050 5.0 4 80 11.5 0 10 7 5 40 180
    0.030 3.8 4 60 11.5 0 10 7 5 40 180

    TGM-7 LED White on Elegoo Mars Pro

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 6 4 100 11.5 0 10 7 5 40 180
    0.050 4.5 4 80 11.5 0 10 7 5 40 180
    0.030 3.4 4 60 11.5 0 10 7 5 40 180

    DMD-21 LED Sand on Elegoo Mars Pro

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 5.3 4 90 11.5 0 10 7 5 40 180
    0.050 4.0 4 70 11.5 0 10 7 5 40 180
    0.030 3.0 4 60 11.5 0 10 7 5 40 180

    DMD-31 DLP Beige and Grey on Elegoo Mars Pro

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 9.1 4 120 11.5 0 10 7 5 40 180
    0.050 6.8 4 90 11.5 0 10 7 5 40 180
    0.030 5.1 4 70 11.5 0 10 7 5 40 180

  • Elegoo Mars 2 Mono

    We do not have recommended settings for Elegoo Mars 2 Mono 3D printer yet. Please contact us at support@ameralabs.com if you have found good settings for this printer.

  • Epax X1K Mono

    We do not have recommended settings for Epax X1K MOno 3D printer yet. Please contact us at support@ameralabs.com if you have found good settings for this printer.

  • Epax X10 8.9 inch 4K Mono

    These are recommended 3D printing settings for Epax X10 8.9 inch 4K Mono 3D printer. Use these as a starting point and adjust based on the results you get. We recommend printing AmeraLabs town calibration part and following its guide to find perfect settings for your printer.

    AMD-3 LED Black on Epax X10 8.9 inch 4K Mono

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 1.6 4 40 15 0 10 8 5 40 180
    0.050 1.2 4 30 15 0 10 8 5 40 180
    0.030 0.9 4 20 15 0 10 8 5 40 180

    AMD-3 LED Grey on Epax X10 8.9 inch 4K Mono

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 1.9 4 40 15 0 10 8 5 40 180
    0.050 1.4 4 30 15 0 10 8 5 40 180
    0.030 1.1 4 20 15 0 10 8 5 40 180

    TGM-7 LED Grey on Epax X10 8.9 inch 4K Mono

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 2.3 4 40 15 0 10 8 5 40 180
    0.050 1.7 4 30 15 0 10 8 5 40 180
    0.030 1.3 4 20 15 0 10 8 5 40 180

    TGM-7 LED White on Epax X10 8.9 inch 4K Mono

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 2.1 4 40 15 0 10 8 5 40 180
    0.050 1.5 4 30 15 0 10 8 5 40 180
    0.030 1.2 4 20 15 0 10 8 5 40 180

    DMD-21 LED Sand on Epax X10 8.9 inch 4K Mono

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 1.9 4 40 15 0 10 8 5 40 180
    0.050 1.4 4 30 15 0 10 8 5 40 180
    0.030 1.1 4 20 15 0 10 8 5 40 180

    DMD-31 DLP Beige and Grey on Epax X10 8.9 inch 4K Mono

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 3.2 4 40 15 0 10 8 5 40 180
    0.050 2.4 4 30 15 0 10 8 5 40 180
    0.030 1.8 4 20 15 0 10 8 5 40 180

  • Epax X133 4K Mono

    We do not have recommended settings for Epax X133 4K Mono 3D printer yet. Please contact us at support@ameralabs.com if you have found good settings for this printer.

  • Epax X156

    We do not have recommended settings for Epax X156 3D printer yet. Please contact us at support@ameralabs.com if you have found good settings for this printer.

  • Epax E6

    Epax E6 Printer 3D printing settings for AmeraLabs resins

    These are recommended 3D printing settings for Epax E6 3D printer. Use these as a starting point and adjust based on the results you get. We recommend printing AmeraLabs town calibration part and following its guide to find perfect settings for your printer.

    AMD-3 LED Black on Epax E6

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 1.4 4 30 11.5 0 10 7 5 40 180
    0.050 1.0 4 20 11.5 0 10 7 5 40 180
    0.030 0.8 4 20 11.5 0 10 7 5 40 180

    AMD-3 LED Grey on Epax E6

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 1.7 4 30 11.5 0 10 7 5 40 180
    0.050 1.3 4 20 11.5 0 10 7 5 40 180
    0.030 1.0 4 20 11.5 0 10 7 5 40 180

    TGM-7 LED Grey on Epax E6

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 2.3 4 30 11.5 0 10 7 5 40 180
    0.050 1.7 4 20 11.5 0 10 7 5 40 180
    0.030 1.3 4 20 11.5 0 10 7 5 40 180

    TGM-7 LED White on Epax E6

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 2 4 30 11.5 0 10 7 5 40 180
    0.050 1.5 4 20 11.5 0 10 7 5 40 180
    0.030 1.1 4 20 11.5 0 10 7 5 40 180

    DMD-21 LED Sand on Epax E6

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 1.7 4 30 11.5 0 10 7 5 40 180
    0.050 1.3 4 20 11.5 0 10 7 5 40 180
    0.030 1.0 4 20 11.5 0 10 7 5 40 180

    DMD-31 DLP Beige and Grey on Epax E6

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 2.9 4 40 11.5 0 10 7 5 40 180
    0.050 2.2 4 30 11.5 0 10 7 5 40 180
    0.030 1.7 4 20 11.5 0 10 7 5 40 180

  • Epax E10 4K

    Epax E10 4K Printer 3D printing settings for AmeraLabs resins

    These are recommended 3D printing settings for Epax E10 3D printer. Use these as a starting point and adjust based on the results you get. We recommend printing AmeraLabs town calibration part and following its guide to find perfect settings for your printer.

    AMD-3 LED Black on Epax E10

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 1.5 4 30 11.5 0 10 7 5 40 180
    0.050 1.1 4 20 11.5 0 10 7 5 40 180
    0.030 0.9 4 20 11.5 0 10 7 5 40 180

    AMD-3 LED Grey on Epax E10

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 1.9 4 30 11.5 0 10 7 5 40 180
    0.050 1.4 4 20 11.5 0 10 7 5 40 180
    0.030 1.1 4 20 11.5 0 10 7 5 40 180

    TGM-7 LED Grey on Epax E10

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 2.5 4 40 11.5 0 10 7 5 40 180
    0.050 1.9 4 30 11.5 0 10 7 5 40 180
    0.030 1.4 4 30 11.5 0 10 7 5 40 180

    TGM-7 LED White on Epax E10

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 2.2 4 40 11.5 0 10 7 5 40 180
    0.050 1.6 4 30 11.5 0 10 7 5 40 180
    0.030 1.2 4 30 11.5 0 10 7 5 40 180

    DMD-21 LED Sand on Epax E10

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 1.9 4 30 11.5 0 10 7 5 40 180
    0.050 1.4 4 30 11.5 0 10 7 5 40 180
    0.030 1.1 4 20 11.5 0 10 7 5 40 180

    DMD-31 DLP Beige and Grey on Epax E10

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 3.2 4 30 11.5 0 10 7 5 40 180
    0.050 2.4 4 30 11.5 0 10 7 5 40 180
    0.030 1.8 4 20 11.5 0 10 7 5 40 180

  • Epax X10

    We do not have recommended settings for Epax X10 3D printer yet. Please contact us at support@ameralabs.com if you have found good settings for this printer.

  • Epax X1-DJ

    Epax X1-DJ Printer 3D printing settings for AmeraLabs resins

    These are recommended 3D printing settings for Epax X1-DJ 3D printer (original version with 40W LED light source and color LCD). Use these as a starting point and adjust based on the results you get. We recommend printing AmeraLabs town calibration part and following its guide to find perfect settings for your printer.

    AMD-3 LED Black on Epax X1-DJ

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 4.7 4 70 11.5 0 10 7 5 40 180
    0.050 3.5 4 60 11.5 0 10 7 5 40 180
    0.030 2.6 4 40 11.5 0 10 7 5 40 180

    AMD-3 LED Grey on Epax X1-DJ

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 5.8 4 90 11.5 0 10 7 5 40 180
    0.050 4.4 4 70 11.5 0 10 7 5 40 180
    0.030 3.3 4 50 11.5 0 10 7 5 40 180

    TGM-7 LED Grey on Epax X1-DJ

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 7.8 4 120 11.5 0 10 7 5 40 180
    0.050 5.8 4 90 11.5 0 10 7 5 40 180
    0.030 4.4 4 70 11.5 0 10 7 5 40 180

    TGM-7 LED White on Epax X1-DJ

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 6.8 4 120 11.5 0 10 7 5 40 180
    0.050 5.1 4 90 11.5 0 10 7 5 40 180
    0.030 3.4 4 70 11.5 0 10 7 5 40 180

    DMD-21 LED Sand on Epax X1-DJ

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 5.8 4 90 11.5 0 10 7 5 40 180
    0.050 4.4 4 70 11.5 0 10 7 5 40 180
    0.030 3.3 4 50 11.5 0 10 7 5 40 180

    DMD-31 DLP Beige and Grey on Epax X1-DJ

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 10 4 100 11.5 0 10 7 5 40 180
    0.050 7.5 4 80 11.5 0 10 7 5 40 180
    0.030 5.6 4 60 11.5 0 10 7 5 40 180

  • Epax X1

    Epax X1 Printer 3D printing settings for AmeraLabs resins

    These are recommended 3D printing settings for Epax X1 3D printer (original version with 40W LED light source and color LCD). Use these as a starting point and adjust based on the results you get. We recommend printing AmeraLabs town calibration part and following its guide to find perfect settings for your printer.

    AMD-3 LED Black on Epax X1

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 4.7 4 70 11.5 0 10 7 5 40 180
    0.050 3.5 4 60 11.5 0 10 7 5 40 180
    0.030 2.6 4 40 11.5 0 10 7 5 40 180

    AMD-3 LED Grey on Epax X1

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 5.8 4 90 11.5 0 10 7 5 40 180
    0.050 4.4 4 70 11.5 0 10 7 5 40 180
    0.030 3.3 4 50 11.5 0 10 7 5 40 180

    TGM-7 LED Grey on Epax X1

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 7.8 4 120 11.5 0 10 7 5 40 180
    0.050 5.8 4 90 11.5 0 10 7 5 40 180
    0.030 4.4 4 70 11.5 0 10 7 5 40 180

    TGM-7 LED White on Epax X1

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 6.8 4 120 11.5 0 10 7 5 40 180
    0.050 5.1 4 90 11.5 0 10 7 5 40 180
    0.030 3.8 4 70 11.5 0 10 7 5 40 180

    DMD-21 LED Sand on Epax X1

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 5.8 4 90 11.5 0 10 7 5 40 180
    0.050 4.4 4 70 11.5 0 10 7 5 40 180
    0.030 3.3 4 50 11.5 0 10 7 5 40 180

    DMD-31 DLP Beige and Grey on Epax X1

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 10 4 100 11.5 0 10 7 5 40 180
    0.050 7.5 4 80 11.5 0 10 7 5 40 180
    0.030 5.6 4 60 11.5 0 10 7 5 40 180

  • Elegoo Saturn

    Elegoo Saturn Printer 3D printing settings for AmeraLabs resins

    These are recommended 3D printing settings for Elegoo Saturn 3D printer. Use these as a starting point and adjust based on the results you get. We recommend printing AmeraLabs town calibration part and following its guide to find perfect settings for your printer.

    AMD-3 LED Black on Elegoo Saturn

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 2.5 4 40 11.5 0 10 7 5 40 180
    0.050 1.9 4 30 11.5 0 10 7 5 40 180
    0.030 1.4 4 30 11.5 0 10 7 5 40 180

    AMD-3 LED Grey on Elegoo Saturn

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 3.2 4 50 11.5 0 10 7 5 40 180
    0.050 2.4 4 40 11.5 0 10 7 5 40 180
    0.030 1.8 4 30 11.5 0 10 7 5 40 180

    TGM-7 LED Grey on Elegoo Saturn

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 4.2 4 70 11.5 0 10 7 5 40 180
    0.050 3.2 4 50 11.5 0 10 7 5 40 180
    0.030 2.4 4 40 11.5 0 10 7 5 40 180

    TGM-7 LED White on Elegoo Saturn

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 3.7 4 70 11.5 0 10 7 5 40 180
    0.050 2.8 4 50 11.5 0 10 7 5 40 180
    0.030 2.1 4 40 11.5 0 10 7 5 40 180

    DMD-21 LED Sand on Elegoo Saturn

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 3.2 4 50 11.5 0 10 7 5 40 180
    0.050 2.4 4 40 11.5 0 10 7 5 40 180
    0.030 1.8 4 30 11.5 0 10 7 5 40 180

    DMD-31  DLP Beige and Grey on Elegoo Saturn

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 5.4 4 80 11.5 0 10 7 5 40 180
    0.050 4.1 4 60 11.5 0 10 7 5 40 180
    0.030 3.1 4 40 11.5 0 10 7 5 40 180

  • Elegoo Mars 3

    Elegoo Mars 3 Printer 3D printing settings for AmeraLabs resins

    These are recommended 3D printing settings for Elegoo Mars 3 3D printer. Use these as a starting point and adjust based on the results you get. We recommend printing AmeraLabs town calibration part and following its guide to find perfect settings for your printer.

    AMD-3 LED Black on Elegoo Mars 3

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 1.4 4 15 11.5 0 10 7 5 40 180
    0.050 1.1 4 15 11.5 0 10 7 5 40 180
    0.030 1 4 10 11.5 0 10 7 5 40 180

    AMD-3 LED Grey on Elegoo Mars 3

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 2.0 4 20 11.5 0 10 7 5 40 180
    0.050 1.5 4 15 11.5 0 10 7 5 40 180
    0.030 1.1 4 15 11.5 0 10 7 5 40 180

    TGM-7 LED Grey on Elegoo Mars 3

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 2.1 4 20 11.5 0 10 7 5 40 180
    0.050 1.6 4 20 11.5 0 10 7 5 40 180
    0.030 1.2 4 15 11.5 0 10 7 5 40 180

    TGM-7 LED White on Elegoo Mars 3

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 1.7 4 20 11.5 0 10 7 5 40 180
    0.050 1.3 4 15 11.5 0 10 7 5 40 180
    0.030 1 4 10 11.5 0 10 7 5 40 180

    DMD-21 LED Sand on Elegoo Mars 3

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 2.0 4 20 11.5 0 10 7 5 40 180
    0.050 1.5 4 15 11.5 0 10 7 5 40 180
    0.030 1.1 4 15 11.5 0 10 7 5 40 180

    DMD-31 DLP Beige and Grey on Elegoo Mars 3

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 3.4 4 35 11.5 0 10 7 5 40 180
    0.050 2.6 4 25 11.5 0 10 7 5 40 180
    0.030 1.9 4 20 11.5 0 10 7 5 40 180

  • Elegoo Mars 2 Pro Mono

    Elegoo Mars 2 Pro Mono Printer 3D printing settings for AmeraLabs resins

    These are recommended 3D printing settings for Elegoo Mars 2 Pro Mono 3D printer. Use these as a starting point and adjust based on the results you get. We recommend printing AmeraLabs town calibration part and following its guide to find perfect settings for your printer.

    AMD-3 LED Black on Elegoo Mars 2 Pro Mono

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 3.7 4 60 11.5 0 10 7 5 40 180
    0.050 2.8 4 50 11.5 0 10 7 5 40 180
    0.030 2.1 4 40 11.5 0 10 7 5 40 180

    AMD-3 LED Grey on Elegoo Mars 2 Pro Mono

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 4.7 4 70 11.5 0 10 7 5 40 180
    0.050 3.5 4 60 11.5 0 10 7 5 40 180
    0.030 2.6 4 40 11.5 0 10 7 5 40 180

    TGM-7 LED Grey on Elegoo Mars 2 Pro Mono

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 5.8 4 90 11.5 0 10 7 5 40 180
    0.050 4.4 4 70 11.5 0 10 7 5 40 180
    0.030 3.3 4 50 11.5 0 10 7 5 40 180

    TGM-7 LED White on Elegoo Mars 2 Pro Mono

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 5.3 4 90 11.5 0 10 7 5 40 180
    0.050 4 4 70 11.5 0 10 7 5 40 180
    0.030 3 4 50 11.5 0 10 7 5 40 180

    DMD-21 LED Sand on Elegoo Mars 2 Pro Mono

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 4.7 4 70 11.5 0 10 7 5 40 180
    0.050 3.5 4 60 11.5 0 10 7 5 40 180
    0.030 2.6 4 40 11.5 0 10 7 5 40 180

    DMD-31 DLP Beige and Grey on Elegoo Mars 2 Pro Mono

    Layer Thickness (mm) Exposure Time (s) Bottom Layers (count) Bottom Exposure Time (s) Light-Off Delay (s) Bottom Light-Off Delay (s) Bottom Lift Distance (mm) Lifting Distance (mm) Bottom Lift Speed (mm/min) Lifting Speed (mm/min) Retraction Speed (mm/min)
    0.100 7.9 4 100 11.5 0 10 7 5 40 180
    0.050 6 4 80 11.5 0 10 7 5 40 180
    0.030 4.5 4 60 11.5 0 10 7 5 40 180

  • Ackuretta FreeShape 120

    Ackuretta FreeShape 120 Printer 3D printing settings for AmeraLabs resins

    These are recommended 3D printing settings for Ackuretta FreeShape 120 3D printer. Use these as a starting point and adjust based on the results you get. We recommend printing AmeraLabs town calibration part and following its guide to find perfect settings for your printer.

    AMD-3 LED Black on Ackuretta FreeShape 120

    Layer Thickness (mm) Illumination Time (s) First Layers (count) First Layers  Illumination Time (s) Wait Before print (s) First Layers Wait Before Print (s) First Layers Lift After Print (mm) Lift After Print (mm) Z-axis Peel Speed  (μm/s) Return Speed (μm/s) Slow Peel Height (μm) Slow Peel Speed (μm/s)
    0.100 5.5 4 130 1 1 8 6 800 5000 2000 200
    0.050 4 4 100 1 1 8 6 800 5000 2000 200
    0.030 3.5 4 80 1 1 8 6 800 5000 2000 200

    AMD-3 LED Grey on Ackuretta FreeShape 120

    Layer Thickness (mm) Illumination Time (s) First Layers (count) First Layers  Illumination Time (s) Wait Before print (s) First Layers Wait Before Print (s) First Layers Lift After Print (mm) Lift After Print (mm) Z-axis Peel Speed  (μm/s) Return Speed (μm/s) Slow Peel Height (μm) Slow Peel Speed (μm/s)
    0.100 6.5 4 130 1 1 8 6 800 5000 2000 200
    0.050 5 4 100 1 1 8 6 800 5000 2000 200
    0.030 4.5 4 80 1 1 8 6 800 5000 2000 200

    TGM-7 LED Grey on Ackuretta FreeShape 120

    Layer Thickness (mm) Illumination Time (s) First Layers (count) First Layers  Illumination Time (s) Wait Before print (s) First Layers Wait Before Print (s) First Layers Lift After Print (mm) Lift After Print (mm) Z-axis Peel Speed  (μm/s) Return Speed (μm/s) Slow Peel Height (μm) Slow Peel Speed (μm/s)
    0.100 8 4 130 1 1 8 6 800 5000 2000 200
    0.050 6 4 100 1 1 8 6 800 5000 2000 200
    0.030 5.5 4 80 1 1 8 6 800 5000 2000 200

    TGM-7 LED White on Ackuretta FreeShape 120

    Layer Thickness (mm) Illumination Time (s) First Layers (count) First Layers  Illumination Time (s) Wait Before print (s) First Layers Wait Before Print (s) First Layers Lift After Print (mm) Lift After Print (mm) Z-axis Peel Speed  (μm/s) Return Speed (μm/s) Slow Peel Height (μm) Slow Peel Speed (μm/s)
    0.100 7.5 4 130 1 1 8 6 800 5000 2000 200
    0.050 5.5 4 100 1 1 8 6 800 5000 2000 200
    0.030 5 4 80 1 1 8 6 800 5000 2000 200

    DMD-21 LED Sand  on Ackuretta FreeShape 120

    Layer Thickness (mm) Illumination Time (s) First Layers (count) First Layers  Illumination Time (s) Wait Before print (s) First Layers Wait Before Print (s) First Layers Lift After Print (mm) Lift After Print (mm) Z-axis Peel Speed  (μm/s) Return Speed (μm/s) Slow Peel Height (μm) Slow Peel Speed (μm/s)
    0.100 6.5 4 130 1 1 8 6 800 5000 2000 200
    0.050 5 4 100 1 1 8 6 800 5000 2000 200
    0.030 4.5 4 80 1 1 8 6 800 5000 2000 200

    DMD-31 DLP Beige and Grey  on Ackuretta FreeShape 120

    Layer Thickness (mm) Illumination Time (s) First Layers (count) First Layers  Illumination Time (s) Wait Before print (s) First Layers Wait Before Print (s) First Layers Lift After Print (mm) Lift After Print (mm) Z-axis Peel Speed  (μm/s) Return Speed (μm/s) Slow Peel Height (μm) Slow Peel Speed (μm/s)
    0.100 11.3 4 120 1 1 8 6 800 5000 2000 200
    0.050 8.5 4 80 1 1 8 6 800 5000 2000 200
    0.030 6.4 4 70 1 1 8 6 800 5000 2000 200

Sign up for our Newsletter

This website stores cookies on your computer. These cookies are used to collect information about how you interact with our website and allow us to remember you. To find out more, see our Privacy Policy.

I agree
